LF340 Watts

Lead Free Automatic Re-seating Temperature and Pressure Relief Valves

Series LF340, LF340X Automatic Reseating Temperature and Pressure Relief Valves are used in commercial water heater applications to provide automatic temperature and pressure protection to hot water supply tanks and hot water heaters. They feature a bronze body with NPT male inlet and NPT female outlet connections, stainless steel spring and thermostat tube, tamper-resistant bonnet screws, automatic reseating feature, and test lever. Model LF340 has a 3 in. (80mm) thermostat. Model LF340X has an 8 in. (200mm) thermostat. Series LF340, LF340X are ASME rated and CSA listed. Temperature Relief: 210°F (99°C). Pressure Relief Range: 75 to 150psi (5.2 to 10.3 bar). Standard Pressure Settings: 75, 100, 125, or 150psi (5.27, 7.03, 8.79, or 10.55 bar).

Features

  • Automatic reseating feature
  • Stainless steel spring and thermostat tube
  • Lead Free* bonze body
  • Valve provides automatic temperature and pressure protection to hot water storage tanks and water heaters

Select a Model

Select options below to identify the UPC, Order Code, and Repair Kit for a specific LF340
