713
×
![]()
Part of the Control Accessories Series
Ordering Code: 713
UPC: 779655071306
3-Way Mixing Valve, 1 1/2 IN Brass
The 3-Way Brass Mixing Valve 713 is used to mix supply water from a hydronic source with water returning from a system. It is designed for use in either closed loop or open loop hydronic systems. This 3-way valve has standard female NPT threads, as well as a maximum leak through rate of 1 percent to allow for water expansion during temperature changes. The valve position can be manually set using the handle. An Actuating Motor 741 or 743 can be used to automatically operate the valve.
Features
- 3-Way mixing valve
- Brass construction to resist corrosion
- 1 1/2 inch connection size
- Maximum leak through rate of 1 percent to allow for water expansion during temperature changes
| Specifications | |
|---|---|
| Markets | Commercial Buildings with BAS, Multifamily Homes, Single-Family Homes, Small Commercial Buildings |
