Trap Doors Type K
Trap Doors - Type K 150 PSF Hinged Cover
Type K Trap Door - 150 PSF Hinged Cover is aluminum construction, single or double-leaf design with engineered lift assistance for one-handed operation. Cover is 1/4 inch steel diamond patterned plate. Lifting mechanism is cam-action hinges pivoting on torsion bars, providing controlled operation and checking downward motion when closing. Hardware is zinc plated and chromate sealed. Finish is mill plated with bituminous coating applied to the frame exterior. Available in four frame opening dimensions.
Features
- Aluminum construction with single or double-leaf design
- Controlled opening operation and checking downward closing motion
- Hardware is zinc plated and chromate sealed
- Available in four frame opening dimensions
Literature
-
- Installation Instructions - Trap Doors Type K,Trap Doors Type J,Trap Doors Type H-20
- Installation Instructions - Trap Doors Type K,Trap Doors Type J,Trap Doors Type H-20 - French
- Installation Instructions - Trap Doors Type K,Trap Doors Type J,Trap Doors Type H-20 - Spanish
- Specification Sheet - Trap Doors Type K
Select a Model
Select options below to identify the UPC, Order Code, and Repair Kit for a specific Trap Doors Type K
No results found
Share this Product
Approval/Certification Information
For product-specific approval information, please refer to the product’s specification sheet (see literature section above) or ask a Watts representative. Some certification agencies allow you to search by product name and brand.
