757DCDA-OSYXPIV-CFM 3

Part of the 757DCDA Series

Ordering Code: 0111206

UPC: 098268259971

Lead Free Model Available

3 In Ss Double Check Detector Assembly, Osy Shutoff Valves X Post Indicator Valve, Cubic Feet Meter

Specifications
Backflow Preventer Type Double Check Detector Assembly
Body Finish Stainless Steel
Body Material Stainless Steel
Body Pattern Inline
BrandName Watts
Bypass Yes
Cap And Tether No
Elbow Fitting No
Hazard Protection Level Non Health Hazard
Hot And Harsh Water No
Hydrant Connection No
Inlet Connection Size 3 IN
Inlet Connection Type Flanged Joint
Inlet Shutoff Valve Type Outside Stem And Yoke Gate Valve
Inlet Thread Type Does Not Apply To Product
LeadFree NO
Maximum Temperature-Fahrenheit 140
Maximum Working Pressure-BAR 12.10
Maximum Working Pressure-PSI 175
Meter Type CFM
Minimum Temperature-Fahrenheit 33
ModelNumber 757DCDA-OSYXPIV-CFM 3
Outlet Connection Size 3 IN
Outlet Connection Type Flanged Joint
Outlet Shutoff Valve Type Post Indicator Valve
Outlet Thread Type Does Not Apply To Product
Part Number 0111206
Polymer Coating No
Pressure Operation Continuous
Protection Type Backpressure and Backsiphonage
Seat Material Engineered Plastic
Series 757DCDA
Strainer No
