TDV
Triple Duty Valves
TDV
Triple Duty Valves
Features
- For use on single, double, and vertical in-line pumps
- Combines three functions: positive shutoff, silent check, and flow control into a single valve
- Saves on space, installation time, and system cost
- Can be changed from straight pattern to angle pattern in the field
Series TDV Triple Duty Valves are triple function valves used in flow measurement applications to eliminate the requirement of a hand-tight shutoff valve, a check valve, and a flow control valve on the pump system. It consists of a ductile iron body construction with grooved ends and anti-rotation lugs, two NPT connections on each side of the valve seat, two brass metering ports with non-slam silent check valves and gasketed caps, brass drain taps, bronze disc, stainless steel valve stem, stainless steel spring, and optional flange adapters. Series TDV provides a quiet system operation and is ideal in single, double, and vertical in-line pump applications.
Approval/Certification Information
For product-specific approval information, please refer to the product’s specification sheet (see literature section above) or ask a Watts representative. Some certification agencies allow you to search by product name and brand.
Literature
Select a Model
Select options below to identify the UPC, Order Code, and Repair Kit for a specific TDV
