Part of the LFWP12B Series

Ordering Code: 0653194

UPC: 098268004410

Lead Free: YES

1 1/2 Cf X 1 1/2 Mpt In Lead Free Brass Crimpring (TM) Male Threaded Adapter

This lead free CrimpRing (TM) adapter is used to make a straight transition between copper pipe and potable or radiant heating PEX tubing. This 1 1/2 crimp by 1 1/2 inch male threaded adapter is made of lead free poly alloy and must be joined to the PEX tubing using a copper crimp ring to form a fast, reliable, and permanent seal. It is recommended to use an electric crimp tool to make the crimp connection.

Product Features

  • UPC Certified
  • NSF Certified
  • May be used with any certified SDR9 CTS PEX tubing
  • Manufactured from lead free brass
Brand Name Watts
Brass Insert No
Finish Lead Free Brass
Fitting Name Adapter
Inlet Connection Size 1 1/2 IN
Inlet Connection Size-Metric 38 MM
Inlet Connection Type Male Threaded
Inlet Material Lead Free Brass
Inlet Thread Type Does Not Apply To Product
Inner Diameter Does Not Apply To Product
Lead Free YES
Material Lead Free Brass
Maximum Working Pressure-BAR 6.90
Maximum Working Pressure-PSI 100
Maximum Working Temperature-Celsius 82.00
Maximum Working Temperature-Fahrenheit 180
Minimum Temperature - Celsius 1.70
Minimum Temperature-Fahrenheit 35
Model Number LFWP12B-2424PB
O-ring Material Does Not Apply To Product
Outer Diameter Does Not Apply To Product
Outlet Connection Size 1 1/2 IN
Outlet Connection Type Male Threaded
Outlet Material Does Not Apply To Product
Outlet Thread Type NPT
Part Number 0653194
Series LFWP12B
Suitable for Gas Service No
