Part of the LFWPPME12 Series

Ordering Code: 0653392

UPC: 098268148718

Lead Free: YES

3/4 In Lead Free Waterpexa Astm Ppsu F1960 Closed 3 Port Tee

This Polyphenylsulfone ASTM PPSU F1960 multi tee is used to make a three way connection between WaterPEXa tubing. This 3/4 inch inlet F1960 by 1/2 inch F1960 outlets. F1960 branch tee must be joined to the WaterPEXa tubing using a F1960 PEX sleeve to form a fast, reliable, and permanent seal. It is recommended that a specialized tool be used to make the connection.

Product Features

  • For making a three way connection with WaterPEXa tubing
  • Special tool recommended
  • Provides a leak proof seal
  • Manufactured from Polyphenylsulfone
Brand Name Watts
EANUCCCode 098268148718
Finish Polyphenylsulfone
Inlet Connection Size 3/4 IN
Inlet Connection Size-Metric 19 MM
Inlet Connection Type Expansion
Inlet Material Polyphenylsulfone
Inlet Thread Type Does Not Apply To Product
Lead Free YES
Material Polyphenylsulfone
Maximum Working Pressure-BAR 12.00
Maximum Working Pressure-PSI 87
Maximum Working Temperature-Celsius 90.00
Maximum Working Temperature-Fahrenheit 194
Minimum Temperature - Celsius 0.00
Minimum Temperature-Fahrenheit 32
Outlet Connection Size 1/2 IN
Outlet Connection Type Expansion
Outlet Material Polyphenylsulfone
Outlet Thread Type Does Not Apply To Product
Part Number 0653392
Second Outlet Connection Size 3/4 IN
Second Outlet Connection Type Expansion
Second Outlet Material Polyphenylsulfone
Second Outlet Thread Type Does Not Apply To Product
Series LFWPPME12
Suitable for Gas Service No
Tee Type Standard
