LFWPPME1212-08X4PB
×
![]()
Discontinued
Part of the LFWPPME12 Series
Ordering Code: 0653397
UPC: 098268148787
Lead Free: YES
3/4 In Lead Free Waterpexa Astm Ppsu F1960 Open 4 Port Tee
This Polyphenylsulfone ASTM PPSU F1960 flow through tee is used to make a three way connection between WaterPEXa tubing. This 3/4 inch F1960 with 1/2 inch F1960 branch tee must be joined to the WaterPEXa tubing using a F1960 PEX sleeve to form a fast, reliable, and permanent seal. It is recommended that a specialized tool be used to make the connection.
- Manufactured from Polyphenylsulfone
- For making a multi port outlet with 4 1/2 inch connections with WaterPEXa tubing
- Special tool recommended
- Provides a leak proof seal
| Specifications | |
|---|---|
| Brand | Watts |
| Buy American Act Compliant | NO |
| EAN | 098268148787 |
| Finish | Polyphenylsulfone |
| Inlet Connection Size | 3/4 IN |
| Inlet Connection Size-Metric | 19 MM |
| Inlet Connection Type | Expansion |
| Inlet Material | Polyphenylsulfone |
| Inlet Thread Type | Does Not Apply To Product |
| Lead Free | YES |
| Material | Polyphenylsulfone |
| Maximum Working Pressure-BAR | 12.00 |
| Maximum Working Pressure-PSI | 87 |
| Maximum Working Temperature-Celsius | 90.00 |
| Maximum Working Temperature-Fahrenheit | 194 |
| Minimum Temperature - Celsius | 0.00 |
| Minimum Temperature-Fahrenheit | 32 |
| Outlet Connection Size | 1/2 IN |
| Outlet Connection Type | Expansion |
| Outlet Material | Polyphenylsulfone |
| Outlet Thread Type | Does Not Apply To Product |
| Part Number | 0653397 |
| Series | LFWPPME12 |
| Suitable for Gas Service | No |
| Tee Type | Standard |
