LF25AUB-DU-HP-Z3(W/PRESS) 3/4

Part of the LF25AUB-Z3 Series

Ordering Code: 88007069

UPC: 098268002560

Lead Free: YES

3/4 In Lead Free Water Pressure Reducing Valve, Press X Press, Polymer Seat, High Range 75-125 Psi

This 3/4 inch lead free brass water pressure reducing valve for high pressure ranges is designed to reduce incoming water pressure to protect plumbing systems and reduce water consumption for commercial, industrial and residential applications. The easy maintenance assembly consists of a replaceable seat module, with Viega ProPress (R) connections and a bypass feature to control thermal expansion pressure. The temperature range is 33 to 160 degrees F (0.5 to 71 degrees C), suitable for up to 300 PSI (20.7 BAR). The high pressure range is 75 to 125 PSI (518 to 863 kPa) with the standard setting at 90 PSI (621 kPa).

Product Features

  • High pressure applications
  • Integral stainless steel strainer removable for cleaning
  • Replaceable seat module
  • Sealed spring cage with stainless steel cage screws
Specifications
BrandName Watts
LeadFree YES
ModelNumber LF25AUB-DU-HP-Z3(W/PRESS) 3/4
Part Number 88007069
Series LF25AUB-Z3
