BP30
By-Pass Control Relief Valves
BP30
By-Pass Control Relief Valves
Features
- By-pass control relief valve protects equipment by allowing excess volume to be by-passed back to the source
- Rugged bronze body with sensitive rubber diaphragm
- Spring and adjustment handle are free from contact with the liquids being controlled
- Easy-to-operate tee handle facilitates pressure change
Series BP30 By-Pass Control Relief Valves are used in commercial, residential and industrial applications to regulate liquid pressure as supplied by a positive pressure pump. These diaphragm-operated type valves protect equipment by opening at the desired setting to allow excess volume to be by-passed back to the source. Series BP30 consists of a bronze body construction with NPT threaded male inlet and NPT threaded female outlet, sensitive rubber diaphragm, polytetrafluoroethylene (PTFE) disc, spring and adjustment handle, and a tee handle. Models available in various pressure ranges.
Approval/Certification Information
For product-specific approval information, please refer to the product’s specification sheet (see literature section above) or ask a Watts representative. Some certification agencies allow you to search by product name and brand.
Literature
Select a Model
Select options below to identify the UPC, Order Code, and Repair Kit for a specific BP30
