B6080-M1 1/2 Watts

Discontinued - Replaced By: LFB6080G2 1/2

Part of the B6080 Series

Ordering Code: 0894227

UPC: 098268915631

Lead Free: NO

1/2 In Standard Port Bronze Ball Valve, Npt Threaded

This 1/2 IN 2-piece NPT threaded full port bronze ball valve, model B6080M1, is used in commercial and industrial applications for a full range of liquids and gases. It features virgin PTFE seat and seal. A full port orifice ensures minimal pressure drop, while the virgin PTFE stem packing seal and thrust washer and chrome plated brass ball provide lasting service.

Product Features

  • Blowout proof pressure retaining stem
  • Threaded NPT end connections
  • Durafill seats
  • Bronze
Specifications
Actuation No
Assembled Dry No
Balance Stop Plate No
Ball Material Chrome Plated Brass
Body Finish Bronze
Body Material Bronze
BrandName Watts
Class Rating Does Not Apply To Product
Control Type Lever Handle
CV Rating 15
Electrical Rating Does Not Apply To Product
Inlet Connection Size 1/2 IN
Inlet Connection Type Female Threaded
Inlet Thread Type NPT
LeadFree NO
Maximum Temperature-Fahrenheit 350
Minimum Temperature-Fahrenheit 0
ModelNumber B6080-M1 1/2
Operating Torque 60
Outlet Connection Size 1/2 IN
Outlet Connection Type Female Threaded
Outlet Thread Type NPT
Part Number 0894227
Port Type Full
Seat Material Virgin PTFE
Series B6080
Stem Packing Material PTFE
Stem Shaft Material Brass
Stem Type Blowout Proof
Thrust Washer Material PTFE
Valve Style 2-piece
WOG Rating 600 PSI
