Part of the TDV Series

Ordering Code: 0036615

UPC: 098268633818

Lead Free: NO

8 In Triple Duty Valve

This 8 inch triple duty valve, Model TDV, is a triple function valve used in flow measurement applications to eliminate the requirement of a hand-tight shutoff valve, a check valve, and a flow control valve on the pump system. It consists of ductile iron body construction with grooved ends and anti-rotation lugs, two NPT connections on each side of the valve seat, two brass metering ports with non-slam silent check valve and gasket cap, brass drain tap, bronze disc, stainless steel valve stem, and stainless steel spring.

Product Features

  • EPDM seat
  • Anti-rotation lug
  • Grooved connection
  • Stainless steel valve stem
Body Material Ductile Iron
Brand Name Watts
EANUCCCode 098268633818
Inlet Connection Size 8 IN
Inlet Connection Size-Metric 200 MM
Inlet Connection Type Grooved Joint
Lead Free NO
Maximum Temperature-Fahrenheit 230
Maximum Working Pressure-BAR 26.00
Maximum Working Pressure-PSI 375
Outlet Connection Size 8 IN
Outlet Connection Type Grooved Joint
Part Number 0036615
Series TDV
