FS-204-W

Part of the FS-204-W Series

Ordering Code: 00067101

UPC: 098268968149

Lead Free: Not In Scope

Wet Location Flow Switch, Nema 4, Two 7/8 In Electrical Knock-Outs, For 1/2 In Conduit, 1 In Npt Connection

This wet location flow switch, model FS-400-W, is used to start or stop electrically operated equipment such as burners, pumps, or alarms by detecting liquid flow through piping. It is designed for use in water media application and is not intended for use of highly corrosive fluids. This flow switch has a switch enclosure rating of NEMA 4, for accurate monitoring of liquid flow in pipelines.

Product Features

  • Single pole double throw switch for operating signal devices
  • Universal design - replaces switches by McDonnell & Miller, Taco, Penn and others
  • EPDM seal for superior performance over mechanical bellows
  • Four heavy duty stainless steel paddles
Specifications
Brand Name Watts
Inlet Connection Size 1 IN
Inlet Connection Type Male Threaded
Lead Free Not In Scope
Maximum Temperature-Fahrenheit 250
Maximum Working Pressure-PSI 160
Model Number FS-204-W
Part Number 00067101
Series FS-204-W
