FBV-3C-TH 1
×
![]()
Discontinued - Replaced By: LFFBV-3C-TH 1
Part of the FBV-3C Series
Ordering Code: 0621002
UPC: 098268461701
1 IN 2-Piece Full Port Brass Ball Valve, Female NPT End Connection with T-Handle
This 1 inch 2-piece, full port, brass ball valve is used in commercial and industrial applications for a full range of liquids and gases. It features a bottom-loaded blowout-proof stem, virgin PTFE seats, thrust washer, and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter and a steel tee handle with threaded end connections. The pressure rating is 600 psi WOG; 150 psi WSP and the temperature range is 0 to 400 degrees F (-18 C to 204 C).
Features
- Threaded connections
- Brass body
- Fluorocarbon elastomer stem O-ring prevents stem leaks
- Certified to NSF/ANSI standard 61/8
| Specifications | |
|---|---|
| Actuation | No |
| Assembled Dry | No |
| Balance Stop Plate | No |
| Ball Material | Brass |
| Body Finish | Brass |
| Body Material | Brass |
| Brand | Watts |
| Buy American Act Compliant | NO |
| Control Type | Lever Handle |
| EAN | 098268461701 |
| Inlet Connection Size | 1 IN |
| Inlet Connection Size-Metric | 25 MM |
| Inlet Connection Type | Female Threaded |
| Inlet Thread Type | NPT |
| Lead Free | NO |
| Maximum Temperature-Fahrenheit | 400 |
| Minimum Temperature - Celsius | -18.00 |
| Minimum Temperature-Fahrenheit | 0 |
| Outlet Connection Size | 1 IN |
| Outlet Connection Type | Female Threaded |
| Outlet Thread Type | FPT |
| Part Number | 0621002 |
| Port Type | Full |
| Seat Material | Virgin PTFE |
| Series | FBV-3C |
| Stem Packing Material | Virgin PTFE |
| Stem Shaft Material | Brass |
| Stem Type | Bottom Loaded Blowout Proof |
| Thrust Washer Material | Virgin PTFE |
| Valve Style | 2-piece |
| WOG Rating | 600 PSI |
