740

Boiler Pressure Relief Valves

Series 740 Boiler Pressure Relief Valves are used in hot water space heating boiler applications to protect against excessive pressure on all types of hot water space heating boiler equipment. They have an iron body construction with expanded outlet drain connections for hot water space heating boilers, non-metallic disc-to-metal seating, stainless steel spring, and test lever. Series 740 offers large discharge capacity, resists corrosive water conditions, resists sticking and freezing, and prevents water and sediment from being trapped in the seat. It is designed for emergency safety relief and shall not be used as an operating control. Pressure Range: 30 to 75psi (2 to 5 bar) with corresponding high ratings from 925,000 to 10,700,000 BTU/hr.

Features

  • Iron body with expanded outlets
  • Non-mechanical seat-to-disc alignment will not stick or freeze
  • Seat is located above drain to prevent water from being trapped and sediment from fouling the seat
  • Valve protects hot water space heating boiler equipment from excessive pressure

Select a Model

Select options below to identify the UPC, Order Code, and Repair Kit for a specific 740

Approval/Certification Information

For product-specific approval information, please refer to the product’s specification sheet or ask a Watts representative. For general information regarding any approval certification partners identified in the specification sheet, please visit our certification partners’ websites:


ASSE CSA FM Approvals NSF
UL ULC USC WQA
