G4000M1
2-Piece, Full Port, Cast Iron Flanged Ball Valves
G4000M1
2-Piece, Full Port, Cast Iron Flanged Ball Valves
Features
- Used in commercial HVAC and steam applications
- Ideal for replacing cast iron gate valves
- Same end-to-end dimensions as conventional flanged iron gate valves
- FDA approved epoxy-coated valve available
Series G4000M1 2-Piece, Full Port, Cast Iron Flanged Ball Valves are used in commercial HVAC and steam applications. It features a 125psi steam rating, stainless steel ball and stem, PTFE seats and packing, a steel-plated stop plate, and a ductile iron handle. Series G4000M1 has quarter turn operation, positive shutoff, and is ideal for replacing cast iron gate valves. The G4000M1 features Lead Free* construction to comply with Lead Free* installation requirements. Pressure Rating is 125psi WSP, 200psi CWP.
Approval/Certification Information
For product-specific approval information, please refer to the product’s specification sheet (see literature section above) or ask a Watts representative. Some certification agencies allow you to search by product name and brand.
Literature
Select a Model
Select options below to identify the UPC, Order Code, and Repair Kit for a specific G4000M1
No results found
| Model | Product Used On - Series or Model | Kit Contents |
|---|---|---|
|
BSK-G4000M1 2
Ball and Stem Kit |
Series G4000M1 Flanged Ball Valve</br></br> |
Ball and stem</br> |
|
SSK-G4000M1 3
Seat and Seal Kit |
Series G4000M1 Flanged Ball Valve</br></br> |
Seat and seal</br> |
