LF886V-DOSY-LM 6

Discontinued - Replaced By: LF886V-DOSY-LM-FS 6

Part of the LF886V Series

Ordering Code: 0683237

UPC: 098268079722

Lead Free: YES

6 IN DI Reduced Pressure Detector Backflow Preventer Assy, Dom OSY Shutoffs, Clapper Check Modules, Less Meter, SS RV Seat, N Pattern, ArmorTek Coating

  • Ductile iron body construction with patented 3-part advanced epoxy coating system designed to limit both microbial induced (MIC) and exposed metal substrate corrosion
  • Combines the use of a stainless-steel relief valve seat and stainless-steel check components for maximum performance and durability
  • Detector bypass assembly, less meter
  • Appropriate for health hazard applications
Specifications
ArmorTek Technology Yes
Backflow Preventer Type Reduced Pressure Zone Detector Assembly
Body Finish Epoxy Coated Using ArmorTek Technology
Body Material Ductile Iron
Body Pattern N-Pattern
Brand FEBCO
Buy American Act Compliant NO
Bypass No
Bypass Size Does Not Apply To Product
Cap And Tether No
Disc Material Rubber
EAN 098268079722
Elbow Fitting No
Hazard Protection Level Health Hazard
Hot And Harsh Water No
Inlet Connection Size 6 IN
Inlet Connection Size-Metric 152.4 MM
Inlet Connection Type Flanged Joint
Inlet Shutoff Valve Type Outside Stem And Yoke Gate Valve
Lead Free YES
Maximum Temperature-Fahrenheit 140
Maximum Working Pressure-BAR 12.10
Maximum Working Pressure-PSI 175
Meter Type No Meter
Minimum Temperature - Celsius 1.00
Minimum Temperature-Fahrenheit 33
Outlet Connection Size 6 IN
Outlet Connection Type Flanged Joint
Outlet Shutoff Valve Type Outside Stem And Yoke Gate Valve
Part Number 0683237
Polymer Coating No
Pressure Operation Continuous
Protection Type Backpressure and Backsiphonage
Seat Material Stainless Steel
Series LF886V
Strainer Yes
Technologies Does Not Apply To Product
Tradename MasterSeries(R)
